In the remaining 9 leads the exploring electrode is still just one electrode but the reference is obtained by combining two or three electrodes.Īt any given instant during the cardiac cycle all ECG leads analyze the same electrical events but from different angles. Three of these leads are easy to understand, since they are simply the result of comparing electrical potentials recorded by two electrodes one electrode is exploring, while the other is a reference electrode.
The 12-lead ECG displays, as the name implies, 12 leads which are derived by means of 10 electrodes. Importantly, the vast majority of recommended ECG criteria (e.g criteria for acute myocardial infarction) have been derived and validated using the 12-lead ECG. The 12-lead ECG offers outstanding possibilities to diagnose abnormalities. Numerous ECG lead systems and constellations of leads have been tested but the standard 12-lead ECG is still the most used and the most important lead system to master. Each ECG lead is presented as a diagram (sometimes called a curve). The electrocardiograph (ECG machine) compares, amplifies and filters the electrical potential differences recorded by the electrodes and presents the results as ECG leads.
Where the heart leads read online skin#
By placing electrodes on the skin it is possible to detect these electrical currents. It was also explained that the electrical currents are conducted all the way to the skin, because the tissues and fluids surrounding the heart, indeed the entire human body, acts as electrical conductors. In the previous discussion it was clarified how de- and repolarization generates electrical current. Thus, the electrical potential difference is the difference in the electrical potential detected by two (or more) electrodes. In electrocardiology these measurement points are the skin electrodes. Electric potential difference is defined as a difference in electric potential between two measurement points. These ions flow across cell membranes (so that the cell can de- and repolarize) and between cells via gap junctions (so that the depolarization can spread between the cells).Įlectrical potential difference arise as the electrical impulse travels through the heart. In electrocardiology the charged particles are represented by intra- and extracellular ions (Na +, K +, Ca 2+). The movement of charged particles generates an electrical current.
Electrophysiological basis of the ECG leads Note that the terms unipolar leads and bipolar leads are not recommended because all ECG leads are bipolar, since they compare electrical currents in two measurement points.
The chest leads may also be referred to as precordial leads. This article will discuss the ECG leads in detail and no prior knowledge is required. The standard ECG – which is referred to as a 12-lead ECG since it includes 12 leads – is obtained using 10 electrodes. These 12 leads consists of two sets of ECG leads: limb leads and chest leads. An ECG lead is a graphical description of the electrical activity of the heart and it is created by analysing several electrodes. In other words, each ECG lead is computed by analysing the electrical currents detected by several electrodes.
An electrode is a conductive pad that is attached to the skin and enables recording of electrical currents. ECG leads: from electrodes to limb leads, chest leads & 12-lead ECGīefore discussing the ECG leads and various lead systems, we need to clarify the difference between ECG leads and ECG electrodes.
